Hikvision Fingerprint Access Control DS-K1T201MF

d

Hikvision Fingerprint Access Control DS-K1T201MF

85,000.00

Compare

Hikvision Fingerprint Access Control DS-K1T201MF

System Parameters
Fingerprint Recognition Duration: 1:1≤1s, 1:3000≤1.5s
Valid Card/ Swiping Record: 100,000 Cards and 300,000 Swiping Card Records
Operation System: Linux
Storage: 256M Storage
FRR (False Rejection Rate): ≤0.01%
FAR (False Accept Rate): ≤0.001%
Card Reading Mode: Supports EM card reading (DS-K1T201EF/EF-C)
Supports Mifare card reading, including card No. reading, and sector reading & writing (DS-K1T201MF/MF-C)
Fingerprint Recognizer: Optical Fingerprint Recognizer Module
Fingerprint Capacity: Max. 5000 Fingerprints;Up to 10 Local Collected Fingerprint Templates for Each Person
Processor: 32 Bit High-performance Processor



Device Interfaces
Accessible Card Reader: Card Reader
Communication Mode: TCP/IP, Wi-Fi
Output Interface: Lock Relay × 1, Alarm Relay × 1
Transmission Rate: TCP/IP, WIFI: 10/100Mbps Self-adaptive,
RS-485: 19200 bps-N-8-1
Input Interface: Doorbell Button × 1, Door Sensor × 1, Alarm Input × 2, Tamper-Proof Switch × 1, Exit Button × 1
USB Interface: USB2.0



General
LCD Screen: 320×240 LCD-TFT Display Screen
Working Current: ≤500mA
Key Board: 17 Keys
Power Supply: 12VDC
Audio: 1 Buzzer, 1 Loudspeaker
LED Indicator: Power/Status
Working Humidity: 10% to 90% (Non-Condensing)
Working Temperature : -20°C to +65°C (-4°F to +149°F)
Dimensions (L×W×H): 137mm × 142mm × 35mm (5.4” × 5.6” × 1.4”)
Weight: 400g (0.88lb)
