Camera |
Image Sensor | 1/2.9? 2Megapixel progresive CMOS |
Effective Pixels | 1920H)x1080(V) |
RAM/ROM | 256MB/16MB |
Scanning System | Progressive |
Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s |
Minimum Illumination | 0.1Lux/F2.0(Color), 0Lux/F2.0(IR on) |
S/N Ratio | More than 50dB |
IR Distance | Distance up to 30m(98ft) |
IR On/Off Control | Auto/ Manual |
IR LEDs | 24 |
Lens |
Lens Type | Fixed |
Mount Type | Board-in |
Focal Length | 2.8 mm (3.6 mm optional) |
Max. Aperture | F2.0/F2.0 |
Angle of View | H:110?/83?,V:57?/44? |
Focus Control | Fixed |
Close Focus Distance | N/A |
DORI Distance | Lens | Detect | Observe | Recognize | Identify |
2.8 mm | 45m(147ft) | 18m(59ft) | 9m(30ft) | 5m(16ft) |
3.6 mm | 57m(187ft) | 23m(75ft) | 11m(33ft) | 6m(20ft) |
PTZ |
Pan/Tilt Range | Pan:0? ~355? ;Tilt:0? ~65? ;Rotation:0? ~355? |
Video |
Compression | H.264+/H.264 |
Streaming Capability | 2 Streams |
Resolution | 1080P(1920?1080)/1.3M(1280?960)/720P(1280?720)/D1(704?576/704?480)/ CIF(352?288/352?240) |
Frame Rate | 2M (1 ~ 25/30fps)s) |
D1/CIF(1 ~ 25/30fps) |
Bit Rate Control | CBR/VBR |
Bit Rate | H264:24K ~ 8192Kbps |
Day/Night | Auto(ICR) / Color / B/W |
BLC Mode | BLC / HLC / DWDR |
