| System |
| Main Processor |
Quad-core embedded processor |
| Operating System |
Embedded LINUX |
| Aduio and Video |
| IP Camera Input |
16/32 Channel |
| Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 |
| VGA: 1920×1080, 1280×1024, 1280×720 |
| Decoding Capacity |
2ch@4K 30fps, 8ch@1080P 30fps |
| Multi-screen Display |
16ch: 1/4/8/9/16 |
| 32ch: 1/4/8/9/16/25/36 |
| OSD |
Camera title, Time, Camera lock, Motion detection, Recording |
| Recording |
| Compression |
Smart H.265+/H.265/Smart H.264+/H.264 |
| Resolution |
8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc. |
| Record Rate |
200Mbps |
| Bit Rate |
16Kbps ~ 20Mbps Per Channel |
| Record Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop |
| Record Interval |
1 ~ 120 min (default: 60 min), Pre-record:1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Video Detection and Alarm |
| Trigger Events |
Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18),Video Loss and Tampering |
| Alarm input |
4 Channel |
| Alarm output |
2 Channel |
| Playback and Backup |
| Playback |
1/4/9/16 |
| Search Mode |
Time /Date, MD and Exact Search(accurate to second), Smart search |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play,Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device/Network |
