8 Core Outdoor Singlemode Fiber Optic Cable
Features
- Good mechanical and temperature performance
- High strength loose tube that is hydrolysis resistant
- Special tube filling compound ensure a critical protection of fiber
- PE sheath protects cable from ultraviolet radiation
Technical Parameters of 8 core fiber
| Cable
type |
8 core Fiber
count |
Tubes | Fillers | Cable diameter
mm |
Cable weight
Kg/km |
Tensilse Strength
Long/Short term N |
Crush Resistance
Long/Short term N |
Bedning Radius
Dynamic/Static mm |
| GYTA/S-2-6 | 2-6 | 1 | 4 | 9.5 | 80 | 600/1500 | 300/1000 | 10/20 |
| GYTA/S-8-12 | 8-12 | 2 | 3 | 9.5 | 80 | 600/1500 | 300/1000 | 10/20 |
| GYTA/S-14-18 | 14-18 | 3 | 2 | 9.5 | 80 | 600/1500 | 300/1000 | 10/20 |
| GYTA/S-20-24 | 20-24 | 4 | 1 | 9.5 | 80 | 600/1500 | 300/1000 | 10/20 |
| GYTA/S-26-30 | 26-30 | 5 | 0 | 9.5 | 80 | 600/1500 | 300/1000 | 10/20 |
| GYTA/S-32-36 | 32-36 | 6 | 0 | 9.7 | 97 | 1000/3000 | 300/1000 | 10/20 |
| GYTA/S-38-48 | 38-48 | 4 | 1 | 10.5 | 109 | 1000/3000 | 300/1000 | 10/20 |
| GYTA/S-50-60 | 50-60 | 5 | 0 | 10.5 | 109 | 1000/3000 | 300/1000 | 10/20 |
| GYTA/S-62-72 | 62-72 | 6 | 0 | 11.5 | 126 | 1000/3000 | 300/1000 | 10/20 |
| GYTA/S-74-84 | 74-84 | 7 | 1 | 13.2 | 153 | 1000/3000 | 300/1000 | 10/20 |
| GYTA/S-86-96 | 86-96 | 8 | 0 | 13.2 | 153 | 1000/3000 | 300/1000 | 10/20 |
| GYTA/S-98-108 | 98-108 | 9 | 1 | 14.6 | 182 | 1000/3000 | 300/1000 | 10/20 |
| GYTA/S-110-120 | 110-120 | 10 | 0 | 14.6 | 182 | 1000/3000 | 300/1000 | 10/20 |
| GYTA/S-122-132 | 122-132 | 11 | 1 | 16.5 | 221 | 1000/3000 | 300/1000 | 10/20 |
| GYTA/S-134-144 | 134-144 | 12 | 0 | 16.5 | 221 | 1000/3000 | 300/1000 | 10/20 |
